BT-T216_SNBC New Beiyang

Home > Printing and Scanning Products > Kiosk Printer > MAX.216mm Kiosk Printer

Kiosk Printer

MAX.216mm Kiosk Printer

BT-T216

Product Specifications

Specification	ltem	Relevant Data
Print	Print method	Direct thermal printing
	Resolution	203/300DPI
	Print width	Max.203mm
	Print speed	203 DPl: 100mm/s, 300 DPl: 75mm/s
	Memory	FLASH: 1MB(2MB/4MB); SDRAM: 203 DPI:1MB, 300 DPI:1.5MB
	Interface	Standard: USB
Barcode Font	Barcode	1D: UPC-A, UPC-E, EAN-8, EAN-13, Code 39, Code 93, Code128, ITF, Codabar 2D: PDF417, QR, GS1-DataBar
Barcode Font	Font	Standard ASCll(12x24), Compressed ASCll(9x17), Traditional/simplified Chinese, enlarge(1~6X), rotate(0, 90,180, 270)bold, white/black reverse, underline, upside-down
Paper	Paper type	Continuous paper, Marked paper, Folded paper, 2ST paper
	Paper width	210~216±0.5mm
	Paper thickness	0.06~0.16mm
	Paper roll OD	Max.203mm
	Paper roll ID	25.4mm or 50mm
	Paper out	Full cut
Presenter	Paper out mode	Paper holding/paper retraction/paper ejection
	Paper retraction speed	/
	Paper out speed	/
Optional module	Optional module	/
Power supply	Input	AC 100-240V, 50/60Hz
Power supply	Output	DC 24V,6.25A
Reliability	Print head lifetime	100 KM
Reliability	Cutter lifetime	500,000 cuts
Environment	Operation condition	5~45℃,20~90%RH(40℃)
Environment	Storage condition	-40~60℃,20~93%RH(40℃)
Physics Spec.	Dimension	297(W)x211(D)x88(H)mm(without paper holder)
Physics Spec.	Weight	Approx. 3.8Kg(without paper holder)
Standard	Certification	/
