BTP-M80_SNBC New Beiyang

Home > Printing and Scanning Products > Pos Printer > MAX.72mm Pos Printer

Pos Printer

MAX.72mm Pos Printer

BTP-M80

Product Specifications

Specification	ltem	Relevant Data
Print	Print method	Direct thermal printing
	Resolution	203 DPI
	Print width	Max.72mm
	Print speed	Max.200mm/s
	Memory	FLASH: 4MB, SDRAM: 2MB
	Driver	Windows, MacOs, Linux
	Sensor	Paper end sensor, Cutter sensor, TPH overheatingsensor, Cover opening sensor, Black mark sensor
	Interface	Standard: USB Optional: Ethernet, Wi-Fi, Bluetooth
	Cash drawer control	1 cash drawer
Barcode	Barcode	1D:UPC-A, UPC-E, EAN-8, EAN-13, Code 39, Code 93,Code 128, ITF, Codabar
Barcode	Barcode	2D:QR code, PDF417, DataMatrix
Font	Font	Standard ASCll(12X24), Compressed ASCll(9X17),Traditional/Simplified Chinese
	Character set	95 Alphanumeric,17 types of international charactersOptional: Traditional/Simplified Chinese
	Character modification	Rotate(0°, 90°, 180°, 270°), bold, underline, reverse,enlarge(1~6X)
Graphic	Graphic printing	Bitmap image download and direct bitmap image print
		RAM bitmap dowanload buffer size:64KB
		FLASH bitmap download buffer size: 256KB
Paper	Paper type	Continuous paper, Marked paper
	Paper width	57.5/80±0.5 mm
	Paper thickness	0.06 ~ 0.08mm
	Paper out	Full cut, Partial cut, Tear off
	Paper roll OD	Max.83mm
Power supply	Input	AC 100~240V,50/60Hz
Power supply	Output	DC 24V,1.5A
Reliability	Print head lifetime	150 KM
Reliability	Cutter lifetime	1,500,000 cuts
Environment	Operation condition	5~45℃,20~90%RH(40℃)
Environment	Storage condition	-40~60℃,20~90%RH(40℃)
Dimension	Dimension	125(W)x160(D)x117(H)mm
Weight	Weight	Approx.0.85Kg
Standard	Certification	CCC
