Print

Print   method

Thermal/Thermal  transfer

Resolution

203DPI

300DPI

Print   width (Max.)

108mm

106mm

Print   speed (Max.)

152mm/s

102mm/s

Memory

SDRAM:   32MB

FLASH:   16MB(64MB optional)

Sensor

Photoelectric   sensor

TPH   temperature detection

Thermistor

TPH   position detection

Microswitch

Interfaces

Standard   USB port

Optional:   RS232 serial port, Ethernet, Bluetooth, WiFi (Bluetooth or WiFi)

Paper   existence

Photoelectric   sensor

CPU

32bit   RISC MCP

Barcodes   fonts graphis

Barcode

1D:

Code39,Code93,Codabar,Code128(Subsets   A, B, and C),EAN-13,EAN-8,UPC-A,UPC-E,UPC/EAN Extensions, Planet Code,   Standard 2 of 5,Industrial 2 of 5,Interleaved 2 of 5,LOGMARS,GS1 Data   Bar(RSS)

2D:

PDF 417,MicroPDF417,QR Code,DataMatrix,MaxiCode,GS1 Composite

Character   enlargement/rotation

Rotate   (0°, 90°, 180°, 270°)

Enlarge   (1-10x)

Vector   fonts support stepless scaling

Character   set

Built   in 7 dot matrix fonts and 1 vector font

Support   users to download dot matrix fonts and vector fonts

Graphical

Binary   non-format bitmap, HEX, PCX, BMP and IMG can be download to FLASH，RAM

paper

Paper   types

Continuous   paper, marking paper, label paper, perforated paper

Paper   width (Max.)

118mm

Paper   roll OD (Max.)

127mm(5   inch)

Paper   roll ID

25.4mm(1   inch) /38mm(1.5 inch)

Paper   out

Tear   off/ Rewind/ Peel off (optional)/Cut (optional)

Paper   thickness

0.06~0.25mm

Ribbon

Ribbon   length (Max.)

300m

Ribbon   ID

12.7mm/25.4mm

Operation   interface

Button,   Indicator

1   button,2 indicator

Power   supply

Input

AC   100～240V, 50/60Hz

Output

DC   24V，2.5A

Environment

Operation   conditions

+5℃～45℃, 20%～90%(40℃)

Storage   conditions

-40℃～60℃,   20%～93%(40℃)

Physics   Spec.

Dimensions

280mm(L)   ×218mm(W)×180mm(H)

Weight

Approx.   2.3 Kg(standard)
