BTP-LF258_SNBC New Beiyang

Home > Printing and Scanning Products > Label Printer > MAX.56mm Label Printer

Label Printer

MAX.56mm Label Printer

BTP-LF258

Product Specifications

Specification	ltem	Relevant Data
Print	Print method	Thermal Label Printing	Thermal Receipt Printing
	Resolution	203 DPI	203 DPI
	Print width	Max.56mm	Max.56mm
	Print speed	Max.127mm/s	Max.127mm/s
	Memory	FLASH:8MB; SDRAM:2MB
	Sensor	Paper end sensor, Label gap sensor, Black mark sensor, Coveropening sensor, TPH voltage sensor, TPH overheating sensor
	Driver	Windows, MacOS, Linux
	Button LED,LCD	1 button,1 LED
	Interface	Standard: USB Optional: Serial, Ethernet, Wi-Fi, Bluetooth
Barcode Font Graphic	1D Barcode	Code 39, UPC-A, UPC-E, Interleaved 2 of 5, Code 128, EAN-8,EAN-13,HBIC (code 39 with verify symbol), Codabar,industry/interleaved 2 of 5, storage and transportationCode, UPC2, UPC5, Code 93, Postnet 25(China), UCC/EAN,matrix 25, POSTNET code
	2D Barcode	QR code
	Graphic printing	Binary unformatted bitmap, HEX, BMP and IMG files canbe downloaded to FLASH or RAM
Paper	Paper type	Label paper, Continuous paper, Marked paper
	Paper width	20~62mm
	Paper roll ID	12.7/25.4mm
	Paper out	Tear off
	Paper roll OD	Max.100mm
Ribbon	Ribbon ID	/
	Output	/
Power supply	Input	AC 100-240V, 50/60Hz
	Output	DC 12V, 2A
Environment	Operation condition	5~45℃,20~90%RH(40℃)
	Storage condition	-40~60℃,20~93%RH(40℃)
Dimension	Dimension	125(W)x225(D)x160(H)mm
Weight	Weight	Approx.1.1Kg
Standard	Certification	CCC
